Switch Ubiquiti UniFi WAN Relay RJ45 10G Redundante Administrable

Sobre este producto

• 🔌 4 puertos RJ45: 3 x hasta 10GbE (10/5/2.5/1G) y 1 x Gigabit para alta disponibilidad
• 🔄 Diseno de WAN failover para continuidad de red en despliegues criticos
• ⚡ Doble fuente de poder AC/DC interna redundante (36W)
• 🎛️ Switch administrable Capa 2 con STP, RSTP, LLDP, VLAN 802.1Q y QoS
• 🚀 20 Gbps de ancho de banda y 15 Mpps de reenvio
• 📦 Formato rack 1U con kit de montaje incluido, gestionado desde UniFi

Característica	Detalles
Tipo de producto	Switch de Red
Marca	Ubiquiti
Modelo	USW-WAN-RJ45
UPC	810084699935
Tipo	Switching
Serie	WAN Relay
Features	QoS | VLANs
Status Indicators	System | Ethernet
Rack Height	1U
Procesador	Embedded switching ASIC + ARM
Network Management	Managed
Rack Mountable	Yes
Rack Mounting Kit	Included
Stackable	No
Layer	Layer 2
Half-Duplex Data Transfer Rate	10/100/1000 Mbps
Network Speeds	10/100/1000/2500/5000/10000 Mbps
Compliant Standards (Wired)	IEEE 802.3, 802.3u, 802.3ab, 802.3bz
Connector Type	RJ-45
Switching Protocol	STP, RSTP, LLDP
Switch Bandwidth	20 Gbps (10G In + 10G Out)
Max Forwarding Rates	15 Mpps
Security Protocols	Spanning Tree Protocol (STP) | Basic QoS | 802.1Q VLAN | HTTPS Management | LLDP
Smart Features: Management	UniFi Managed (Controller-based)
Multicast Support	Basic Multicast Forwarding Only
Port Types	RJ45 | WAN
Network Ports and Connectors	(1) 1G/100/10M RJ-45; (3) 10/5/2.5/1 Gbps RJ-45
Fuente de poder	Dual AC/DC Internal, 36W
Ancho	17.42 in. (442.40 mm)
Profundidad	4.72 in. (120.00 mm)
Alto	1.72 in. (43.18 mm)
Peso	5.30 lbs. (2.40 kg)
Operating Temperature Range	23°F - 104°F (-5°C - 40°C)
Operating Humidity Range	10 to 90% Noncondensing
What's in the Box	1 x WAN Relay Switch; 2 x Power Cable; 1 x Rack Mounting Hardware
