Switch de Red Ubiquiti WAN Relay Switch

Sobre este producto

• 🔀 Switch de relevo WAN administrado Capa 2 para failover de WAN sin interrupciones en entornos críticos.
• ⚡ Puertos SFP+ de 10 GbE (uplink y downlink) que garantizan velocidad y ancho de banda de sobra.
• 🔋 Doble fuente de poder integrada y redundante para alta disponibilidad ante fallos eléctricos.
• 🔌 4 puertos: 1 x RJ-45 GbE y 3 x SFP+ con velocidades de hasta 10 Gbps.
• 🗄️ Formato rack 1U con kit de montaje incluido e integración total con la plataforma UniFi Network.
• 🛡️ QoS y VLANs para priorizar tráfico y segmentar la red.

Característica	Detalles
Tipo de producto	Switch de Red
Marca	Ubiquiti
Modelo	WAN Relay Switch with 10 GbE SFP Uplink, 10 GbE SFP Downlink, and Dual Built-In Power Supplies for High Availability
Número de parte	USW-WAN
UPC	810084699928
Tipo	Switching
Serie	WAN Relay
Features	QoS | VLANs | SFP | SFP+
Status Indicators	System | Ethernet | SFP+
Rack Height	1U
Procesador	Embedded switching ASIC + ARM
Network Management	Managed
Rack Mountable	Yes
Rack Mounting Kit	Included
Stackable	No
Layer	Layer 2
Half-Duplex Data Transfer Rate	10/100/1000 Mbps
Network Speeds	1/10/1000/10000Mbps
Compliant Standards (Wired)	IEEE 802.3, 802.3u, 802.3ab, 802.3bz
Connector Type	RJ-45, SFP+
Switching Protocol	STP, RSTP, LLDP
Switch Bandwidth	20 Gbps (10G In + 10G Out)
Max Forwarding Rates	15 Mpps
Security Protocols	Spanning Tree Protocol (STP) | VLANs: IP Based | Basic QoS | 802.1Q VLAN | HTTPS Management | LLDP
Smart Features: Management	UniFi Managed (Controller-based)
Multicast Support	Basic Multicast Forwarding Only
Port Types	RJ45 | SFP+
Network Ports and Connectors	(1) 1 GbE RJ-45; (3) 10/1 GbE SFP+
Fuente de poder	Dual AC/DC Internal, 36W
Ancho	17.40 in. (441.96 mm)
Profundidad	4.72 in. (119.89 mm)
Alto	1.72 in. (43.68 mm)
Peso	5.1 lbs. (2.31 kg)
Operating Temperature Range	23°F - 104°F (-5°C- 40°C)
Operating Humidity Range	10 to 90% Noncondensing
What's in the Box	1 x WAN Relay Switch; 2 x Power Cable; 1x Rack Mounting Hardware
