Switch de Red Ruckus ICX 8200, ICX8200-48F

Sobre este producto

• 🌐 Switch de Red Ruckus ICX 8200: para redes cableadas de oficina y datacenter.
• ✅ The RUCKUS ICX 8200 Switch series is purposely designed to handle next generation wireless first and IoT campus networks
• ✅ These intelligent, scalable edge switches deliver enterprise-class functionality at an affordable price without compromising performance and reliability

Característica	Detalle
Marca	Ruckus
Línea de producto	Ruckus ICX
Modelo	8200
Fabricante	Ruckus Wireless
Flash Memory Installed	8 GB
RAM instalada	4 GB
Advanced Switching	Layer 3
Estándares	IEEE 802.1ab (LLDP), IEEE 802.1AX, IEEE 802.1BR, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad (LACP), IEEE 802.3az, IEEE 802.3x, IEEE 802.3z
Características	Authentication, Authorization and Accounting (AAA), Auto-uplink (auto MDI/MDI-X), BPDU Guard, DHCP snooping, DoS protection, Double VLAN mode, Dynamic ARP Inspection (DAI), Flexible authentication, GARP VLAN Registration Protocol (GVRP), IGMP fast leave, IGMP proxy, IGMP snooping, Inter-Packet Gap (IPG) adjustment, Link Fault Signaling (LFS), MAC address authentication, MAC address filtering, MAC based VLAN, MAC Learning Disable, MLD snooping, Per-VLAN Spanning Tree (PVST), Per-VLAN Spanning Tree Plus (PVST+), Port Loop Detection, Port mirroring, Private VLAN, Quality of Service (QoS), Remote Fault Notification (RFN), Root Guard, Secure Copy (SCP), Static routing, Trusted Platform Module (TPM), Uni-Directional Link Detection (UDLD), Virtual Switch Redundancy Protocol (VSRP) support, Web authentication
Form Factor (Hubs & Switches)	Rack-mountable
Jumbo Frame Support	9216 bytes
MAC Address Table Size	32K entries
Manageable	Yes
Max Units In A Stack	12
Ports	48
Tipo de producto	Switch
Gestión remota	DHCP, SNMP 1, SNMP 2c, SNMP 3, SSH, SSH-2, Telnet
Routing Protocol	GRE, IGMP, IGMPv2, IGMPv3, MLD, MLDv2, OSPF, OSPFv2, OSPFv3, Policy-based routing (PBR), RIP, VRF, VRRP, VRRPE
Stackable	Stackable
Subcategory	Network hubs and switches
Switching Type	Gigabit Ethernet
Interfaces	1 x console RJ-45, 1 x console USB Type-C, 1 x management RJ-45, 1 x USB Type A storage, 4 x 1Gbit/10Gbit/25Gbit SFP/SFP+/SFP28 uplink/stacking, 48 x 100/1000 SFP
Port Quantity	48
Port Type	100/1000 / SFP
Ports Type (2nd)	25 GbE SFP28 (stacking / uplink)
Frequency	50/60 hertz
Potencia	180 watt
Voltaje requerido	AC 100-240 volt
Encryption	AES
Humidity Range Storage	10 - 90% (non-condensing)
Temp. máx. de operación	113 degree Fahrenheit
Max Storage Temperature	158 degree Fahrenheit
Temp. mín. de operación	32 degree Fahrenheit
Min Storage Temperature	-40 degree Fahrenheit
MTBF	1,699,974 Hours
Humedad de operación	10 - 90% (non-condensing)
Airflow Direction	Front to back airflow
Authentication Method	RADIUS, RADSEC, Secure Shell v.2 (SSH2), TACACS, TACACS+
Capacity	ARP entries: 8192, Link Access Groups (LAGs): 128, Ports per LAG: 8, PVLANs supported: 32, QoS priority queues per port: 8, Spanning Tree Protocol instances: 253, Virtual interfaces (VLANs): 4095
Device Type	Internal power supply
Cantidad por empaque	1
Performance	Forwarding capacity: 219 Mpps, Stacking bandwidth: 1.2 Tbps, Switching capacity: 296 Gbps
Ports (2nd) Quantity	4
Alto	1.7 inch
Altura (unidades de rack)	1
Weight	9.48 lbs
Ancho	17.3 inch
Profundidad	11 inch
Color	Black
Certificado ENERGY STAR	No
Cumple EPEAT	No
TAA Compliant	Yes
TCO Certified	No
