Switch de Red Extreme Networks 5420M

Sobre este producto

• 🔌 48 puertos 10/100/1000Base-T más 4 uplinks 1/10/25 Gigabit SFP28
• 🛠️ Switching Layer 3 con soporte IPv4/IPv6 y varios protocolos de enrutamiento
• 🔒 Seguridad con ACL, ARP y QoS por puerto más amplio cumplimiento de estándares
• 🔋 Redundancia de energía con soporte de fuentes internas para servicio ininterrumpido
• 🚀 Alta capacidad de conmutación y forwarding para redes modernas

Característica	Detalle
Marca	Extreme Networks
Línea de producto	Extreme Networks
Modelo	5420M
Fabricante	EXTREME NETWORKS
Advanced Switching	Layer 3
Estándares	IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae
Características	Access Control List (ACL) support, ARP support, Audio Video Bridging (AVB), Equal-Cost Multipath (ECMP), Ethernet Virtual Private Network (EVPN), IPv4 and IPv6 dual stack, Packet filtering, Port-based QoS, Quality of Service (QoS), VLAN support, Zero-touch provisioning (ZTP)
Form Factor (Hubs & Switches)	Rack-mountable
MAC Address Table Size	64K entries
Manageable	Yes
Max Units In A Stack	8
Ports	48
Tipo de producto	Switch
Gestión remota	CLI
Routing Protocol	BGP, BGP-4, OSPF
Stackable	Stackable
Subcategory	Network hubs and switches
Switching Type	Gigabit Ethernet
Interfaces	1 x 1000Base-T RJ-45, 1 x console (micro-USB), 1 x serial (console) RJ-45 out-of-band network management, 1 x USB Type A, 2 x SFP-DD stacking, 4 x 1/10/25GBase-X SFP28 uplink, 48 x 10/100/1000 Base-T RJ-45 with MACsec
Port Quantity	48
Port Type	10/100/1000Base-T
Ports Type (2nd)	1/10/25 Gigabit SFP28
Fuentes instaladas	0
Fuentes soportadas	2
Fuente redundante	Yes
Humidity Range Storage	10 - 95% RH (non-condensing)
Temp. máx. de operación	122 degree Fahrenheit
Max Storage Temperature	158 degree Fahrenheit
Temp. mín. de operación	32 degree Fahrenheit
Min Storage Temperature	-40 degree Fahrenheit
Humedad de operación	10 - 95% RH (non-condensing)
Capacity	ACL entries (egress): 1024, ACL entries (egress): 336, ACL entries (ingress): 1024, ACL entries (ingress): 18000, ARP table (IPv4): 24000, BEB nodes per VSN: 500, Fabric adjacencies per switch: 50, IP interfaces: 1533, IP interfaces: 248, IP multicast entries: 12000, IP multicast entries: 4000, IPv4 routing table entries: 11750, IPv4 routing table entries: 12000, IPv6 neighbor table entries: 12000, IPv6 neighbor table entries: 16000, IPv6 routing table entries: 5750, IPv6 routing table entries: 6000, L2 VSN: 512, L3 VSN: 64, Maximum number of VLANs: 4059, Maximum number of VLANs: 4094, Policy profiles: 63, Queues per port (egress): 8, Unique permit/deny rules per switch: 8120
Device Type	Internal power supply
Cantidad por empaque	1
Performance	Forwarding rate: 279.7 Mpps, Switching capacity: 376 Gbps
Ports (2nd) Quantity	4
Rack Mounting Kit	Included
Alto	1.7 inch
Weight	9.68 lbs
Ancho	17.4 inch
Profundidad	13 inch
Color	Purple
Certificado ENERGY STAR	No
