Switch de Red EnGenius Cloud ECS5512FP

Sobre este producto

• 🔌 8 puertos 10G (100/1000/2500/5000/10000Base-T) más 4 uplinks 10G PoE++
• ⚡ Presupuesto PoE de 420 W para dispositivos de alta potencia
• 🚀 Layer 2+ con 240 Gbps de capacidad de conmutación para mayor rendimiento
• 🔄 Soporta STP, RSTP y MSTP para redundancia de red
• 📡 IGMP y MLD Snooping para filtrado multicast avanzado y eficiencia de red
• ☁️ Elige gestión en la nube u on-premises según tu arquitectura y presupuesto

Característica	Detalle
Marca	EnGenius
Línea de producto	EnGenius Cloud
Modelo	ECS5512FP
Fabricante	Engenius
Flash Memory Installed	128 megabyte
Tecnología de memoria	SDRAM
RAM instalada	512 megabyte
Advanced Switching	Layer 2+
Estándares	IEEE 802.1D, IEEE 802.1p, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x
Características	2MB packet buffer, Access Control List (ACL) support, ARP filtering, ARP inspection, Bandwidth control, Class of Service (CoS), Cloud managed, DHCP relay, DHCP snooping, DiffServ Code Point (DSCP) support, DSCP Trust, Flow control, Full duplex capability, IGMP snooping, Import SSL certificate, IPv4 support, IPv6 support, Link Aggregation, Loopback detection, MAC and IP-based ACLs support, MLD snooping, Multicast filtering function, Port Security, Port-based VLAN, Protocol-based VLANs support, Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP) support, Reset button, Scheduler, Secure backup, Selectable Operation Modes, SNTP support, Spanning Tree Protocol (STP) support, SSH support, Store and forward, Syslog support, Time-controlled ACLs support, VLAN Tagging, Voice VLAN, Weighted Round Robin (WRR)
Form Factor (Hubs & Switches)	Rack-mountable
Jumbo Frame Support	9KB
MAC Address Table Size	32K entries
Manageable	Yes
PoE Budget	420 watt
Ports	8
Power Over Ethernet (PoE)	PoE++
Tipo de producto	Switch
Gestión remota	CLI, HTTP, HTTPS, IPv4, IPv6, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2c, SNMP 3, SSH, Telnet, TFTP
Status Indicators	Fail, LAN, Link/activity/speed, PoE, PoE max, Power
Subcategory	Network hubs and switches
Switching Type	10 Gigabit Ethernet
Interfaces	1 x console RJ-45, 4 x 10Gbit LAN SFP+ uplink, 8 x 10/100/1000/2.5G/5G/10GBase-T (PoE++) RJ-45 PoE++
Port Quantity	8
Port Type	10/100/1000/2.5G/5G/10GBase-T (PoE++)
Ports Type (2nd)	10 Gigabit SFP+ (uplink)
Frequency	50/60 hertz
Power Consumption Operational	745.61 watt
Voltaje requerido	AC 100-240 volt
Encryption	SSL
Temp. máx. de operación	122 degree Fahrenheit
Temp. mín. de operación	32 degree Fahrenheit
Humedad de operación	5 - 95% (non-condensing)
Authentication Method	RADIUS
Capacity	ARP entries: 192, IPv4 routes (static): 63, IPv6 routes: 21, Multicast groups: 256, Packet buffer size: 2 MB, Port security entries: 256, Priority QoS queues: 8, Static ARP entries: 192, VLAN groups: 256, VLAN IDs: 4094
Device Type	Internal power supply
Cantidad por empaque	1
Performance	Switching capacity: 240 Gbps
Ports (2nd) Quantity	4
Rack Mounting Kit	Included
Cables	1 x console cable
Alto	1.7 inch
Altura (unidades de rack)	1
Weight	5.75 lbs
Ancho	9.1 inch
Profundidad	13 inch
Color	Black
Certificado ENERGY STAR	No
Cumple EPEAT	No
TCO Certified	No
