Switch de Red Cisco Catalyst IE3300 Rugged Series

Sobre este producto

• 🏭 Switch modular endurecido (rugged) para aplicaciones industriales y de empresa extendida
• 🔌 16 puertos Gigabit PoE+ más 8 SFP y 4 uplinks 1/10 Gigabit SFP+
• ⚡ Presupuesto PoE+ de 480 W para dispositivos de alta demanda
• 🚀 Conectividad Gigabit Ethernet en formato compacto
• 🛠️ Administrado y montable en rack

Característica	Detalle
Marca	Cisco
Línea de producto	Cisco Catalyst
Modelo	IE3300 Rugged Series
Fabricante	Cisco Systems
Flash Memory Installed	8 GB
RAM instalada	8 GB
Estándares	IEEE 1588v2, IEEE 802.1ab (LLDP), IEEE 802.1ae, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ah, IEEE 802.3u, IEEE 802.3z
Características	Authentication, Authorization and Accounting (AAA), DHCP snooping, DHCPv6 guard, DiffServ Code Point (DSCP) support, Duplicate Address Detection (DAD), Dynamic ARP Inspection (DAI), Embedded Event Manager (EEM), EtherChannel support, Fanless, Flexible NetFlow (FNF), IGMP snooping, IP source guard, IPv6 support, Low-latency queuing (LLQ), Management Information Base (MIB), Media Redundancy Protocol (MRP), MLD snooping, MQC, Network Timing Protocol (NTP), Per-VLAN Rapid Spanning Tree (PVRST), Per-VLAN Spanning Tree Plus (PVST+), Policy based routing, Precision Time Protocol (PTP), Priority Queuing (PQ), PROFINET, Protocol Independent Multicast (PIM), Q-in-Q tunneling, Quality of Service (QoS), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Rapid PVST (RPVST), Remote Switch Port Analyzer (RSPAN), Resilient Ethernet Protocol (REP), Routing Information Protocol (RIP), Security Group Access Control List (SGACL), Spanning Tree Protocol (STP) support, Static routing, Storm Control, Switched Port Analyzer (SPAN), Syslog support, Tunneling, VLAN Trunking Protocol (VTP) v.2
Form Factor (Hubs & Switches)	Rack-mountable
Manageable	Yes
PoE Budget	480 watt
Ports	28
Power Over Ethernet (PoE)	PoE+
Tipo de producto	Switch
Gestión remota	DHCP, HTTPS, MIB, NETCONF, RADIUS, RESTCONF, SNMP, Syslog, TACACS+, YANG
Routing Protocol	BGP, EIGRP, HSRP, IGMP, IGMPv2, IGMPv3, IS-IS, MLD, MSDP, OSPF, OSPFv3, Policy-based routing (PBR), STP
Subcategory	Network hubs and switches
Switching Type	Gigabit Ethernet
Expansion Slots	1 (total) / 1 (free) x SD Memory Card
QSFP Slots	1 Gigabit / 10 Gigabit SFP+ (uplink)
Interfaces	1 x alarm output, 1 x micro-USB, 1 x serial (RS-232) RJ-45, 1 x USB 2.0, 16 x 10/100/1000 Base-T RJ-45 PoE+ - 60 W, 4 x 1/10GBase-X SFP+ uplink, 4 x alarm input, 8 x 100/1000 SFP
Port Quantity	16
Port Type	10/100/1000 (PoE+)
Ports Type (2nd)	100/1000 SFP
Power Consumption Operational	105 watt
Fuente redundante	Yes
Fuente redundante soportada	1+1
Dispositivos integrados	SD card reader
Encryption	TLS 1.3
Temp. máx. de operación	167 degree Fahrenheit
Temp. mín. de operación	-40 degree Fahrenheit
MTBF	265,827 Hours
Authentication Method	RADIUS, Secure Shell (SSH), TACACS+
Capacity	Access Control Lists (PACL/VACL/RACL): 1536, Active VLANs: 1024, Direct IPv4 routes: 8192, GRE tunnels: 10, IGMP multicast groups: 1000, Indirect IPv4 routes: 7000, Indirect IPv6 routes: 1522, IPv4 to SGT binding: 10000, Multiple Spanning Tree Protocol instances: 128, Queues per port: 8, SGT/DGT policies: 2000, Switched virtual interfaces (SVIs): 984, SXP Sessions: 200, Unicast MAC addresses: 24000, VLAN IDs: 4096
Cantidad por empaque	1
Performance	Forwarding bandwidth: 64 Gbps, Forwarding rate: 95.23 Mpps, Switching bandwidth: 128 Gbps
Ports (2nd) Quantity	8
Ports (3rd) Quantity	4
Alto	1.7 inch
Altura (unidades de rack)	1
Weight	10.6 lbs
Ancho	17.5 inch
Profundidad	14 inch
Color	Black
Certificado ENERGY STAR	No
Cumple EPEAT	No
TCO Certified	No
