Switch de Red Aruba HPE Networking 6300F, JL665A#ABA

Sobre este producto

• 🔌 48 puertos 10/100/1000 Base-T PoE+ más 4 uplinks 1/10/25/50G SFP para máxima flexibilidad de conexión
• ⚡ Capacidad de conmutación de 496 Gbps y throughput de 369 Mpps para rendimiento non-blocking
• 🔋 Presupuesto PoE de hasta 740W con HPE Smart Rate multi-gigabit para APs de alta velocidad y dispositivos IoT
• 📚 Aruba Virtual Stacking Framework (VSF) permite apilar hasta 10 switches para escalar y simplificar la gestión
• 🧠 Diseño cloud-céntrico con OS programable AOS-CX y Aruba Network Analytics Engine para monitoreo avanzado del acceso
• 🔌 Alimentación 100-120/200-240 VAC compatible con instalaciones eléctricas estándar

Característica	Detalle
Marca	Aruba
Línea de producto	HPE Aruba
Modelo	6300F
Fabricante	Aruba
Velocidad de reloj	1.8 GHZ
Marca del procesador	ARM
Tipo de procesador	Cortex-A72
Procesadores instalados	1
Flash Memory Installed	32 GB
Tecnología de memoria	DDR4 SDRAM
RAM instalada	8 GB
Advanced Switching	Layer 3
Estándares	IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1t, IEEE 802.1v, IEEE 802.1w, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3ba, IEEE 802.3bj, IEEE 802.3bm, IEEE 802.3bt, IEEE 802.3by, IEEE 802.3bz, IEEE 802.3cc, IEEE 802.3cd, ITU-T G.8032, ITU-T Y.1344
Características	802.1x authentication, 8MB packet buffer, ARP support, BOOTP support, Bootstrap Router (BSR) Mechanism, Bridge protocol data unit (BPDU), Cisco Discovery Protocol (CDP), Class of Service (CoS), Deficit Weighted Round Robin (DWRR), Denial of Service (DoS) protection, DHCP support, DiffServ support, Ethernet Virtual Private Network (EVPN), Fan tray, ICMP Router Discovery Protocol (IRDP), IPv6 support, Link Aggregation, LLDP support, LLDP-MED, Management Information Base (MIB), MLD snooping, Multiple Spanning Tree Protocol (MSTP) support, Multiple VLAN Registration Protocol (MVRP), Neighbor Discovery Protocol (NDP), Network Timing Protocol (NTP), Port mirroring, Quality of Service (QoS), Rapid Reconfiguration of Spanning Tree (RSTP), sFlow, SNMP trap, Strict Priority (SP), Syslog support, Tagged VLAN, Trusted Platform Module (TPM), Type of Service (ToS), Uni-Directional Link Detection (UDLD), Virtual Extensible LAN (VXLAN), Virtual Route Redundancy Protocol (VRRP) support, Virtual Routing and Forwarding (VRF), VLAN support
Form Factor (Hubs & Switches)	Rack-mountable
Jumbo Frame Support	9198 bytes
MAC Address Table Size	32000 entries
Manageable	Yes
Ports	48
Power Over Ethernet (PoE)	PoE+
Tipo de producto	Switch
Gestión remota	HTTP, RMON, SFTP, SNMP 1, SNMP 2c, SNMP 3, SSH, Telnet, TFTP, XRMON
Routing Protocol	BGP, BGP-4, CIDR, IGMP, IGMPv3, MLD, MLDv2, MSDP, OSPF, OSPFv2, PIM-DM
Stackable	Stackable
Subcategory	Network hubs and switches
Switching Type	Gigabit Ethernet
Interfaces	1 x console (USB) Type C, 1 x USB Type A, 4 x 50Gbit LAN SFP56, 48 x 1000Base-T RJ-45 PoE+ - 30 W
Port Quantity	48
Port Type	10/100/1000 (PoE+)
Ports Type (2nd)	50 Gigabit Ethernet SFP56
Frequency	50 - 60 hertz
Potencia	900 watt
Fuentes instaladas	1
Encryption	FIPS 140-2, SSL
Humidity Range Storage	15 - 95% (non-condensing)
Temp. máx. de operación	113 degree Fahrenheit
Max Storage Temperature	158 degree Fahrenheit
Temp. mín. de operación	32 degree Fahrenheit
Min Storage Temperature	-40 degree Fahrenheit
Humedad de operación	15 - 95% (non-condensing)
Airflow Direction	Front to back airflow
Authentication Method	RADIUS, Secure Shell (SSH), TACACS+
Capacity	IGMP groups: 8000, IPv4 ACL entries (egress): 2000, IPv4 ACL entries (ingress): 5000, IPv4 host table capacity: 32000, IPv4 routes (Multicast): 8000, IPv4 routes (Unicast): 64000, IPv6 ACL entries (egress): 500, IPv6 ACL entries (ingress): 1250, IPv6 host table capacity: 32000, IPv6 routes (Multicast): 8000, IPv6 routes (Unicast): 32000, MAC ACL entries (egress): 2000, MAC ACL entries (ingress): 5000, MLD groups: 4000, Switched virtual interfaces (SVIs): 1000
País	United States
Device Type	Internal power supply
Localization	English
Cantidad por empaque	1
Performance	1 Gbps average latency (64-byte packets): 2.28 µs, 10 Gbps average latency (64-byte packets): 1.46 µs, 25 Gbps average latency (64-byte packets): 1.9 µs, 50 Gbps average latency (64-byte packets): 3.49 µs, Stacking bandwidth: 200 Gbps, Switching capacity: 496 Gbps, Switching throughput: 369 Mpps
Ports (2nd) Quantity	4
Alto	1.7 inch
Altura (unidades de rack)	1
Weight	11.24 lbs
Ancho	17.4 inch
Profundidad	12.9 inch
Color	Black
Certificado ENERGY STAR	No
Cumple EPEAT	No
TAA Compliant	Yes
TCO Certified	No
